CETOP 5 Automatic Reciprocating Valve, 80 L/min, 50–200 Bar
4/2RHA10/20
Product Features:
Customers who bought this product also bought these
CETOP 5 Automatic Reciprocating Valve, 80 L/min, 50–200 Bar
CETOP 5 Automatic Reciprocating Valve 4/2 RHA10 is a compact and reliable hydraulic directional control valve designed for automatic switching in hydraulic systems. This 4/2 automatic switching valve enables continuous reciprocating motion by automatically reversing flow direction, making it ideal for applications requiring repeated movement without manual or electrical input.
Designed to mount on a CETOP 5 (ISO 4401-05) subplate, this valve offers easy integration into standard hydraulic systems. It operates within a working pressure range of 50 to 200 bar and supports a flow rate of up to 80 l/min, providing dependable performance across a wide range of mobile and industrial applications.
The valve features an initial switching function via push pins, ensuring correct setup and reliable operation from installation. Built for durability and consistent performance, it is suitable for use with mineral oil-based hydraulic fluids across a wide operating temperature range.
Technical Specifications
| Specification | Details |
|---|---|
| Valve type | 4/2 automatic switching (reciprocating) valve |
| Mounting standard | CETOP 5 (ISO 4401-05) |
| Working pressure | 50 – 200 bar |
| Flow rate | 5 – 80 l/min |
| Working fluid | Mineral oil |
| Fluid viscosity | 10 – 100 mm²/s |
| Filtration level | 25 µm or better |
| Operating temperature | -20°C to +80°C |
| Ambient temperature | -20°C to +50°C |
Common Applications
The CETOP 5 automatic reciprocating valve is widely used in hydraulic systems requiring automatic directional switching, including:
- Hydraulic cylinders – creating continuous back-and-forth motion
- Industrial automation systems – repetitive movement without electrical control
- Material handling equipment – automated positioning and cycling
- Agricultural machinery – oscillating or repetitive hydraulic functions
- Mobile machinery – simple, self-contained hydraulic control solutions
