12V DC Single Acting Hydraulic Power Pack 1.6kW with 4.5L Tank
ZZ003468
Product Features:
Customers who bought this product also bought these
4.5 Litre 12V DC Single Acting Hydraulic Power Pack, 1.6kW
The Flowfit 12V DC single acting hydraulic power pack is a compact mobile power unit designed for tipper trailers, tipping bodies and single-acting hydraulic cylinder applications.
This model is supplied with a 4.5L plastic reservoir and powered by a 12V DC 1.6kW motor, providing hydraulic pressure for lifting with controlled gravity return for lowering.
Common Uses
- Tipper trailers
- Tipping bodies
- Dump trailers
- Trailer hydraulic lifting systems
- Agricultural tipping equipment
- Plant and mobile machinery
- Single-acting hydraulic cylinder systems
Available Reservoir Options
| Part Number | Reservoir Size |
|---|---|
| ZZ017472 | 1.5L plastic reservoir |
| ZZ016049 | 2.5L plastic reservoir |
| ZZ003468 | 4.5L plastic reservoir |
| ZZ009277 | 7L plastic reservoir |
| ZZ003834 | 8L plastic reservoir |
| ZZ010636 | 11L plastic reservoir |
| ZZ010637 | 13L plastic reservoir |
| ZZ016026 | 18L plastic reservoir |
Technical Data
| Specification | Details |
|---|---|
| Power Pack Type | Single acting hydraulic power pack |
| Motor | 12V DC, 1.6kW |
| Pump | 2.1cc/rev gear pump |
| Maximum Flow | 5L/min at 160 bar |
| Pressure Relief Valve | Adjustable 40-200 bar, preset at 160 bar |
| Flow Control | Adjustable flow control for smooth cylinder descent |
| Ports | 3/8" BSP |
| Mounting | Horizontal mounting |
| Duty Cycle | Intermittent duty S3 7% - 42 seconds on / 10 minute cycle |
| Control | Detachable 2-button pendant with 4m lead |
Application note: This power pack is commonly used on tipper applications where hydraulic pressure is required to raise the body and gravity return is used to lower the cylinder.
Important Information
- Designed for single-acting cylinder systems only
- Requires a suitable high-capacity 12V battery
- An inline fuse should be used during installation
- Please check the required reservoir size before ordering
- Ensure the flow rate, pressure rating, duty cycle and oil capacity are suitable for your hydraulic application
Installation & Wiring Guide
Need help wiring your hydraulic power unit? Watch our handy video guide covering Flowfit single-acting and double-acting hydraulic power packs.
Note: Please check the required reservoir capacity and hydraulic system requirements before ordering to ensure the correct power pack option is selected.
