Walvoil SD6 Double-Acting Solenoid Control Kit (8ES3) – Bi-Directional Solenoid Operation, Spring Return to Neutral
5CAN08027
Product Features:
Walvoil SD6 Double-Acting Solenoid Control Kit (8ES3) – Bi-Directional Solenoid Operation, Spring Return to Neutral
Series: 8ES3
Walvoil SD6 Double-Acting Solenoid Control Kit (8ES3) with Spring Return to Neutral is an electro-hydraulic spool control kit designed for use with Walvoil SD6 sectional control valves.
Configured for double-acting solenoid operation, this control kit allows the spool to be actuated electrically in both directions, while automatically returning to the neutral position by spring force when de-energised. It is suitable for hydraulic systems requiring dependable remote valve actuation, controlled spool movement, and safe neutral return functionality.
Key Features
| Valve Compatibility | Suitable for Walvoil SD6 valve sections |
| Control Type | Double-acting solenoid spool control |
| Solenoid Operation | Solenoid controlled in both directions |
| Return Function | Spring return to neutral position |
| Manual Override | Emergency manual override |
Applications
| Mobile Machinery | Suitable for agricultural, construction, and utility equipment using electro-hydraulic valve control |
| Industrial Hydraulic Systems | Ideal for installations requiring electrically actuated spool control |
| Remote Operation | Enables convenient remote control of valve spool movement |
| Automation Integration | Can be incorporated into electro-hydraulic and automated control systems |
| Safety Function | Spring return helps restore the spool to neutral when power is removed |
Operating Features
| Internal Leakage A(B) → T | 15 cm³/min (0.91 in³/min) at Δp = 100 bar (1450 psi), T = 40°C |
| Nominal Voltage Tolerance | +10% |
| Power Rating | 36 W |
| Coil Insulation | Class H |
| Duty Cycle | 100% |
Specifications
| Brand | Walvoil |
| Series Reference | 8ES3 |
| Compatible Valve Series | SD6 |
| Actuation Type | Solenoid control kit |
| Function | Double-acting |
| Spool Control | Solenoid operated in both directions |
| Return Action | Spring return to neutral |
| Additional Feature | Emergency manual override |
