Flowfit Inline Single Acting Hydraulic 20cc Hand Pump For Single Acting Cylinder, 20CC, With Release Hand Knob
PMP20SFF
Product Features:
Customers who bought this product also bought these
Hand-operated hydraulic inline hand pump 20cc for single-acting cylinders/rams with release knob
The Flowfit Inline Single Acting Hydraulic 20cc Hand Pump is a compact, manually operated hydraulic pump designed for use with single acting cylinders. Delivering 20cc of oil displacement per stroke, this inline hand pump provides reliable and controlled hydraulic power in applications where precision, portability, and simplicity are essential.
Engineered for durability and ease of use, the pump features a convenient release hand knob for smooth and controlled pressure release. Its inline design makes it easy to integrate into existing hydraulic systems while maintaining a compact footprint — ideal for workshop, industrial, agricultural, and mobile applications.
Technical Specifications
| Specification | Value |
|---|---|
| Displacement | 20cc |
| Working pressure | Up to 350 bar |
| System type | Single-acting cylinder/ram |
| Valves | Release knob |
| Fluid temperature | -20°C to +80°C |
| Ambient temperature | -20°C to +50°C |
| Filtration | 15 Micron or better |
Typical Applications
- Single-acting hydraulic jacks and rams
- Lifting, lowering and controlled positioning of heavy loads
- Clamping and holding operations in fabrication and assembly
- Light pressing tasks (workshop maintenance and repair work)
- On-site, mobile or remote hydraulic operation where no power supply is available
- Agricultural machinery adjustment and maintenance tasks
- Construction and plant maintenance (portable/manual hydraulic actuation)
- Emergency backup or manual override for powered hydraulic systems
Hand Pump Effort vs Pressure (600mm Lever)
The chart compares the manual force required on a 600mm operating lever as hydraulic pressure increases, across different pump displacements (6cc, 12cc, 25cc and 45cc). As pressure rises, the lever effort rises too — and higher displacement pumps require more effort at the same pressure. Lower displacement pumps are easier to operate at higher pressures, but deliver less oil per stroke (more strokes required).
Which cc is best?
- 6cc – Best for high-pressure work where operator comfort matters most (lowest effort, slowest output).
- 12cc – A strong all-round choice for higher pressure applications with moderate speed.
- 25cc – Better for faster cylinder movement at lower to mid pressures, with higher effort as pressure climbs.
- 45cc – Best when you want maximum flow/fast extension at lower pressures; can become physically demanding at higher pressures.
