Hydrotechnik WLB-DDPG, Bluetooth Digital Datalogging Pressure Gauge, 0 to 160 Bar
WLB-DDPG-0160
Product Features:
Hydrotechnik WLB-DDPG, Bluetooth Digital Datalogging Pressure Gauge, 0 to 160 Bar
The WLB-DDPG Series digital datalogging pressure gauges deliver high-accuracy pressure measurement, display, and recording for up to 48 hours. Designed for both stationary and mobile use, they feature rugged IP67 protection and Bluetooth connectivity via the free Watchlog app. Perfect for testing, calibration, and diagnostics, the WLB-DDPG provides precise, traceable data in a compact, cost-effective solution for industrial and automotive applications.
AVAILABLE MODELS
| Part Number | Measuring Range |
|---|---|
| WLB-DDPG-V016 | -1 to +16 bar |
| WLB-DDPG-0060 | 0 to 60 bar |
| WLB-DDPG-0160 | 0 to 160 bar |
| WLB-DDPG-0250 | 0 to 250 bar |
| WLB-DDPG-0400 | 0 to 400 bar |
| WLB-DDPG-0700 | 0 to 700 bar |
| WLB-DDPG-1000 | 0 to 1000 bar |
TECHNICAL SPECIFICATIONS
| Specification | Details |
|---|---|
| Pressure ranges | Between -1...1000 bar |
| Accuracy | ±0.2% (0.1% and 0.05% accuracies available on request) |
| Pressure units | bar/mbar, kPa/MPa, PSI, kg/cm², mH₂O, inH₂O, ATM |
| Display type | Multifunctional LCD, 4 1/2 digit, with background lighting |
| Display functions | Bar graph, pressure unit, display filter, MIN/MAX value, Overpressure indicator 110% of full scale pressure value (FS) |
| Pressure measuring cell | ≤10 bar piezo resistive, ≥20 bar thin film strain gauge |
| Temperature compensation | 0...50°C |
| Temperature error | 0.005% of full scale pressure value (FS) / K |
| Measuring rate actual value | 10 ms |
| Measuring rate bar graph | 50 ms |
| Thread ISO 1179-2 | G1/4 with NBR gasket, AF27 |
| Process connection material | Stainless steel 1.4404 |
| Medium temperature | -20...80°C |
| Housing connection | 270° axially rotatable |
| Degree of protection DIN EN 60529 | IP67 |
| Dimensions | Ø 90 mm, D=45 mm, H=120 mm with protection cap |
| Materials | Sensor Body 304L, Measuring Cell 316L |
| Ambient conditions | 0...50°C with air humidity ≤85% r.h. |
| Weight | 357 g without 3×AAA batteries fitted |
| Vibration resistance (IEC 60068-2-6) | 5g up to 500 Hz |
| Shock resistance (IEC 60068-2-29) | 25g for 11 ms |
| Auto-off function | Selectable switch-off time 5 minutes |
| Battery type | 3×1.5V AAA |
| Battery operation | 1500 h |
| Datalogger max. data sets | 27000 per recording series |
| Datalogger record series | 1...10 |
| Storage rate | 0.1...64 s – automatic depending on recording duration |
| Max. recording duration | 48 h |
| Data set information | time / actual pressure / MIN/MAX value |
| Digital data transmission | Serial USB 2.0 via USB-C port |
| PC software | Detection as USB data storage device, spreadsheet program (Excel) |
| File format | .csv |
| Mobile device software | Compatible with Watchlog Bluetooth iOS and Android apps for display and datalogging |
| Linearisation | The factory linearisation is changed via OFFSET and INCREASE; a special programming adapter is required. Communication between PC/laptop and digital pressure gauge is via TTL level by means of a PC terminal program |
| Certificate (optional) | UKAS traceable certificate, works test certificate |
