Walvoil VDSRL Direct Acting Sequence Valve – 1/2" BSP, 50 L/min, 50-200 Bar, Aluminium
1200031102
Product Features:
Customers who bought this product also bought these
Walvoil VDSRL Direct Acting Sequence Valve – 1/2" BSP, 50 L/min, 50-200 Bar, Aluminium
Walvoil VDSRL 10-12/TS.S direct acting sequence valve is a robust and reliable solution designed for controlled hydraulic flow sequencing in mobile and industrial systems. It ensures that a secondary hydraulic function is only activated once the required pressure has been reached in the primary circuit.
Built with an aluminium body, this valve provides a strong combination of durability and reduced weight, making it well suited to demanding hydraulic applications. Its direct acting design offers dependable pressure control and efficient sequencing performance across a wide range of systems.
With a nominal flow rate of 50 l/min and a maximum operating pressure of 210 bar, the VDSRL 10-12/TS.S is suitable for higher flow hydraulic circuits. It also features an adjustable pressure setting range of 50–200 bar, allowing flexible setup to meet different application requirements.
Technical Specifications
| Specification | Details |
|---|---|
| Valve type | Direct acting sequence valve |
| Model | VDSRL 10-12/TS.S |
| Body material | Aluminium |
| Port size | 1/2" BSP |
| Nominal flow rate | 50 l/min |
| Maximum operating pressure | 210 bar |
| Pressure setting range | 50–200 bar |
| Fluid | Mineral based oil |
| Viscosity range | 10 to 200 cSt |
| Fluid temperature | -20°C to 80°C (with NBR seals) |
| Environmental temperature | -40°C to 100°C |
Common Applications
The Walvoil VDSRL 10-12/TS.S sequence valve is commonly used in hydraulic systems where functions need to operate in a controlled order. Typical applications include:
- Mobile machinery – sequencing hydraulic functions for smoother operation
- Agricultural equipment – controlling the order of cylinder and auxiliary movements
- Construction machinery – ensuring pressure-dependent operation of secondary circuits
- Industrial hydraulic systems – directing flow only after preset pressure is reached
- General hydraulic installations – improving control, safety, and system efficiency
