Filtrec FRT R1 50 Tank Top Return Filter, 10 Micron Cellulose, 2" BSP, 340 L/min, 4-Hole
FRTR150C10BBB80CMRB
Filtrec FRT R1 50 tank-top hydraulic return filter with 10 micron cellulose, 2" BSP connection and 340 L/min flow rating. Includes 4-hole tank mounting and MRB radial pressure gauge.
Product Features:
Customers who bought this product also bought these
4-Hole Tank-Mounted Hydraulic Return Filter - 10 Micron Cellulose, 2" BSP, 340 L/min
The Filtrec FRT R1 50 is a tank-top hydraulic return filter configured with 10 micron cellulose, a 2" BSP connection and a rated flow of 340 L/min.
Mounted directly on the tank lid, the FRT filters hydraulic oil on the return line before it re-enters the reservoir, while keeping routine element replacement accessible.
Dimensions & Model Reference
| MODEL | A | Ø B1 | B2 | B3 | Ø D1 | Ø D2 | Ø D3 | H1 | H2 | H3 | M | R | WEIGHT (Kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FRT R1 10 | G 3/8" - G 1/2" G 3/4" | 89 | 28.5 | 51 | 67.5 | 24 | 67 | 82 | 60 | 8 | M6 | 150 | 0.45 |
| FRT R1 11 | 155 | 220 | 0.6 | ||||||||||
| FRT R1 20 | G 1/2" G 3/4" G 1" G 1 1/4" | 115 | 67 | 88.5 | 40 | 87 | 192 | 73 | 11 | M8 | 160 | 0.8 | |
| FRT R1 22 | 137 | 210 | 0.9 | ||||||||||
| FRT R1 30 | 218 | 290 | 1.1 | ||||||||||
| FRT R1 31 | 32 | 322 | 390 | 1.3 | |||||||||
| FRT R1 40 | G 1" - G 1 1/4" G 1 1/2" | 175 | 35 | 95 | 130 | 129 | 223 | 90 | M10 | 300 | 2.1 | ||
| FRT R1 43 | 269 | 350 | 2.4 | ||||||||||
| FRT R1 45 | 436 | 520 | 3.1 | ||||||||||
| FRT R1 50 | G 1 1/4" G 1 1/2" G 2" | 220 | 42 | 115 | 175 | 65 | 174 | 164 | 105 | 250 | 2.9 | ||
| FRT R1 51 | 223 | 310 | 3.3 | ||||||||||
| FRT R1 60 | |||||||||||||
| FRT R1 64 | 273 | 360 | 3.9 | ||||||||||
| FRT R1 66 | 423 | 510 | 5.1 |
Dimensions are in mm unless otherwise stated. The FRT R1 50 row is highlighted for quick reference.
Why Use an FRT Tank Top Return Filter?
Tank-top return filtration captures contamination at the end of the hydraulic circuit before oil returns to the reservoir. This helps reduce recirculation of wear particles and keeps routine filter servicing accessible.
Key Benefits
- 10 Micron Cellulose filtration
- 2" BSP return connection
- Flow rating 340 L/min
- 4-Hole tank mounting
- MRB radial pressure gauge
- Tank-top design keeps servicing accessible
Suitable Applications
- Hydraulic reservoir return lines
- Mobile hydraulic machinery
- Agricultural and forestry equipment
- Industrial hydraulic power units
- Plant and material handling equipment
Technical Specification
| Feature | Details |
|---|---|
| Product Type | Tank top hydraulic return filter |
| Model | FRT R1 50 |
| Filtration | 10 Micron Cellulose |
| Port Size | 2" BSP |
| Flow Rate | 340 L/min |
| Tank Mounting | 4-Hole |
| Maximum Operating Pressure | 8 bar |
| Burst Pressure | 16 bar |
| Bypass Valve | 1.7 bar (B version) |
| Seal | NBR |
| Indicator | MRB pressure gauge, radial connection |
| Overall Installed Height | 269 mm |
| Below-Tank Height (H1) | 164 mm |
| Element Removal Clearance | 250 mm |
| Weight | 2.90 kg |
Sizing guidance: Check the stated flow rate against your oil viscosity, operating temperature and acceptable pressure drop to make sure the filter is suitable for your application.
Need Help Choosing the Correct Hydraulic Return Filter?
Our team can help confirm the correct Filtrec return filter, element, port size and flow rating for your hydraulic system.
Contact Us for expert advice, availability and delivery options.
HOUSING tested according to NFPA T3.10.5.1*, ISO 10771*, ISO 3968
PRESSURE:
Max operating: 8 bar
Burst: 16 bar
CONNECTIONS: G 3/8” ÷ G 2
MATERIALS:
Cover and head: aluminium alloy
Bowl: PA6 reinforced
Seal: NBR (FKM on request)
BYPASS VALVE:
Inbuilt in the filter element
B version 1,7 bar
C version 3 bar
ELEMENT tested according to ISO 11170, 2941, 2942, 2943, 3724,3968,16889, 16908, 23181
FILTER MEDIA:
Inorganic microfiber
G06 - G10 - G15 - G25 - G40
Paper: C10 - C25
Synthetic: M05 - M10 - M15
Metal wire mesh: T60
COLLAPSE PRESSURE: 10 bar
TEMPERATURE RANGE:-30°C +100°C
FLUID COMPATIBILITY: Full with HH-HL-HM-HVHETG-HEES (acc. to ISO 6743/4).For use with other fluid please contact us.
